The purpose of this method statement is to provide guidelines and steps for the cctv installation of security systems by describing the Work to be executed, how it is to be executed and making references to other technical standards and relevant national/international standards and Quality Aspects of the work to be undertaken. This procedure covers Installation of CCTV System including brackets, supports wiring & accessories etc. There can be different project specifications which might require separate and customized methods specific to different projects and cctv equipment.

The CRC report laid out how the OBC’s recommendation was aligned with the council’s strategies in the following ways:. A new relationship with citizens: o Citizens will feel safer and there will be less fear of crime as a result of confidence in CCTV ability to prevent and detect crime. A one public sector approach. Looking after your security system is crucial, which is why we have put together this CCTV Maintenance Checklist to keep it effective.(+ FREE PDF Checklist) Call us today Menu. Call us FREE on 0800 030 6068. Sub: installation of 24 nos, of CCTV Cameras in Osler Hostel and 6 CCTV. Be worked out by the firm and quoted in the following format only. 1 General Description: The CCTV system shall be used to monitor and record the hazardous. 1 Vendor should submit quotation in Indian currency,only.May 5, 2011. Cctv security camera installation business plan sample template If you are fascinated by surveillance gadgets, then the sale of CCTV cameras may be your thing. The purpose of this article is to help you get your business on the right footing.

Tools & Equipment Requirements For CCTV Installation

  • Electrician tool Kit
  • Drill machine
  • Tools and spanner sets
  • Crimping tool with crimping bits for all required sizes
  • Line Tester
  • Multimeter
  • Pipe bend and threading machines.
  • Continuity Tester
  • Programming software tools
  • Special tools as per manufacturer requirements

CCTV System Installation Checklist Analogue and IP CCTV Systems Infinique CCTV Systems Installation Checklist w w w. I n f i n i q u e. C o m DS-VS-IOM-201412V01 1 Project Details Checklist Date Client Name Checklist Filled by Contractor Name System Integrator Analogue System IP System Video Analytics.

Method Of CCTV Installation For Cameras

  • Prepare all the materials, equipment and tools that will be necessary during the execution time.
  • Drawing for installation shall be approved and shall be coordinated with other services.
  • Room clearance & proper access shall be provided as per approved program.
  • Location/area shall be ready for site installation. Prior to the installation, the area where the items to be installed shall be inspected to ensure architectural works and finishing are complete and area is free from dust.
  • Ensure that the approved shop/schematic/coordination drawings are current and available with installation team.
  • Avoid installing the cameras close to sources of powerful electromagnetic radiation, such as radio or TV transmitters or close to fluorescent lamps or objects reflecting light, or under unstable light sources, which may cause flickering.

Indoor Fixed Dome IP Camera Ceiling Flush Mount

  • Exact location of the CCTV camera shall be as per approved CCTV Installation layout plan as well and to be coordinated at site to ensure easy access for maintenance in future.
  • Select a location to install the Camera and prepare the ceiling and/or ceiling tile.
  • All the above false ceiling CCTV should have the facility to access the IP Data point for future maintenance.
  • For the CCTV which needs to be fixed on the false ceiling mark with exact dimension to make hole by false ceiling contractor.
  • Attach the template that comes with the Camera to the ceiling and then drill a hole according to the diameter hole marked on the template. Drop down the camera cables through the hole. Drill another small hole for a screw to secure the camera.
  • Remove camera lower dome cover by turning the cover counter clockwise.
  • Pull all the field wiring and power and video connectors.
  • Plug the network cable into the RJ-45 network port on the side of the camera.
  • Where applicable, connect the necessary wiring for alarms and relays.
  • Install the support back plate. Mount the camera on the ceiling using the appropriate hardware.
  • Adjust the Monitoring direction for the camera to adjust the lens in a desired direction.
  • Secure the camera top cover in place.

Indoor Fixed Dome IP Camera – Pipe Bracket Mount

  • Select a location to install the components and applicable mount as per approved cctv installation Layout plan
  • Use the four hole in flanges as template to mark as drill hole in which to position secure mount.
  • Drill the hole into ceiling
  • Feed the wires through the mount
  • Assemble pipe mount to ceiling
  • Connect all wires to camera
  • Assemble camera to mount and fix with screws
  • Install camera dome housing cover.
  • Identification to be made as per approved tagging materials.

Indoor Fixed Dome IP Camera – Channel Support Mount

  • Select a location to install the components and applicable mount as per approved CCTV layout plan.
  • Fix C channel both end to the both side wall.
  • Take data cable through the channel and connect into the camera
  • Install the camera center of the channel with proper nut, bolt & washer
  • Manually adjust the zoom and focus of the lens to the desired field of view

Fixed Wall IP Camera with Housing Wall Mount

  • Select a location to install the components and applicable mount as per approved CCTV
  • Mark and drill the camera housing mounting base or GI Extension bracket hole size into the wall.

Prepare the mounting surface:

  • Drill the Camera Housing mounting base or GI Extension bracket hole size into the wall.
  • If applicable, Fix Suitable G.I extension supports bracket into Concrete wall (Behind Cladding wall )

Install the mount:

  • Install the Camera Housing wall mounting base to the smooth vertical surface or GI extension bracket.
  • If necessary to prevent water damage, apply sealant around the bolt holes between the mount and mounting surface.
  • Install housing into wall bracket.

Pull the wires (Data and power) through the arm starting from the bottom of the mounting plate; pull the wires out through the threaded opening at the bottom of the arm.

Installation Report Format For Cctv Camera

Adjust the monitoring direction for the camera to adjust the housing in a desired direction.

Install the Camera Inside housing using the appropriate hardware. D angelico serial number korea.

Install the lens

  • Remove the cover from the camera lens mount.
  • Screw the lens onto the lens mount. Be careful to prevent dust from entering the space between the lens and the imager. If necessary, use clean, compressed air to remove any foreign matter. Make sure the lens does not touch the camera imager when installed.
  • Connect the auto iris lens to the 4-pin connector located on the side of the camera.

Plug the network cable into the RJ-45 network port on the side of the camera.

Focus the lens:

  • View the camera image using the service port or a Web browser.
  • Press the auto back focus button once to center the focus mechanism. The button is located on the rim of the back box.
  • Manually adjust the zoom and focus of the lens to the desired field of view.

Secure the camera using camera housing and tighten the nuts on the studs. Dg41wv driver for windows 10.

Identification to be made as per tagging – Label given in the approved shop drawings.

Analog Fixed Camera + Encoder For Elevators

  • Exact location of the CCTV Installation Of camera shall be as per approved CCTV drawings.
  • Select a location to install the Camera and prepare the elevator ceiling.

Insider Elevator Car

  • For the CCTV which needs to be fixed on the elevator false ceiling mark with exact dimension to make hole by false Elevator contractor.
  • Attach the template comes with the Camera to the ceiling and then drill a hole according to the 70 mm diameter hole marked on the template. Drop down the camera cables through the hole. Drill another small hole for a screw to secure the camera.
  • Remove camera Lower Dome cover by unscrewing the camera housing ring.
  • Pull all the field wiring and power and video connectors.
  • Mount the camera on the ceiling using the appropriate hardware.
  • Adjust the Monitoring direction for the camera to adjust the lens in a desired direction.
  • Secure the camera top cover in place.

Elevator Machine Room

  • Select a location to install the Encoder as per approved CCTV System Device Layout plan as well and to be coordinated at site to ensure adjacent location to the elevator Control Panel
  • Prepare the mounting surface:
    • Drill the Enclosure hole size into the wall.
    • Fix Junction box on wall surface near the Elevator Control panel.
    • Connect the necessary power and data Conduit into Junction box.
    • Fix the encoder and camera power supply units inside the junction box.
  • Plug the network cable into the RJ-45 network port in Encoder.
  • Pull Co-axial cable from the Elevator control panel to Junction box. the cables are part of elevator Traveling and provided by Elevator contractor .
  • Plug Co-axial cable into BNC Connector port in encoder.
  • Make all electrical connections.
  • Identification to be made as per approved tagging.

Installation Report Format For Cctv Cameras

Installation

Viewline is designed to help drainage contractors produce professional CCTV survey reports at a very reasonable price. Viewline reporting software is MSCC5 compliant (this is the Industry Standard) and WRc Approved. The WRc Approved scheme is recognised and established in a range of industries; providing End-Users and Suppliers confidence that their products are fit-for-purpose.

We provide an annual subscription package that includes all support, updates and upgrades.

Designed by CCTV surveyors to be easy to use, easy to understand and highly professional, Viewline will put your company ahead of the rest.

Hard copy reports are produced in PDF, which is an open standard for electronic distribution. The result is a top quality drain condition reporting program at a very reasonable price that produces industry standard reports, which your customer will easily understand. Other report options include a web page report as well as an option for Microsoft Word reporting (requires Microsoft Office).

Our format incorporates a professional design with your company logo available on each page, as well as site and client details on the front page. Section Header and Observation data are laid out according to the National Standard (BS EN 13508-1:2003).

Our latest version incorporates a site image on the front cover and an easy to understand traffic light system approach for easy interpretation. We use the industry standard Drainage Repair Book (DRB) grade system to classify sections. Grade ‘A’ sections are coloured green, Grade ‘B’ sections are amber and Grade ‘C’ sections are red.

We have also used colour coding to indicate how many scored defects have been reported and their severity.

Our reports are very easy to create and understand. Your clients should understand the condition of their drainage system, almost at a glance. Your clients don’t have to wade through the report, they can simply view our easy to understand coloured info-graphics on the front cover. The first pages of the project indicate the total number and severity of the graded sections contained within the project.

Sections also automatically display their individual DRB grade based on the peak defect severity noted within the section. We’ve tried to make it as easy as A, B, C.

We have also added an interpretation page where you can describe your reporting methodology or use the template we provide.

The Overview section enables you to Grade the section and add more information or remedial recommendations. This information auto-populates the colour-coded grading system and the Overview section.

We feel using the DRB industry standard and adding colour coding will make interpretation of our reports far easier to the non-specialist. The report still details the required information but is built for ease of understanding.

We have listened to our growing army of users and incorporated the best ideas within our industry-leading domestic CCTV surveying product.

Installation Report Format For Cctv

Images of defects are added per section and a site plan can be added as the final page. Video position reference is also added automatically.

Reports can also be sent as a folder to any cloud storage system and viewed as a web page. Your clients can see the report detail with video as soon as it has been uploaded. To this end we have incorporated a very good compression system, meaning video file sizes are very small.

Our main product has been designed for drainage contractors that primarily carry out commercial and domestic CCTV investigations on smaller diameter pipework.

Typical Uses

  • Drainage Investigation
  • Site Surveys
  • Home Buyer Surveys
  • Condition Surveys
  • Build Over Surveys
  • Look-See Surveys
  • Pest Control
  • Pre and Post Lining
  • Pre and Post Cleansing
Installation Report Format For Cctv

We also provide a full MSCC5 product that includes the full coding system as well as auto SRM and DRB grading of sections surveyed.

You can download a trial version to test or contact us, we are generally available during normal working hours. The download button is located to the right.

Cctv Installation Proposal Pdf

(If you are testing live recording and reporting we recommend the Xvid MPEG-4. If you are importing video files we also recommend the installation of the K-Lite mega codec pack).

  • Produce professional hard copy reports with pictures.
  • Overview Page – This is a colour coded, ‘at a glance’ page. The user can classify sections as A, B or C (A being good and C being bad). You can also type your recommendations here. Accessed from the Section detail area.
  • Colour coded, ‘at a glance’, graphical DRB grades on each page.
  • Colour coded defect indications per project and per section.
  • Print to PDF facility.
  • Loaded with a full set of MSCC5 standard codes and observations.
  • Compatible with any CCTV survey system.
  • Record live footage straight to your laptop while you report.
  • Approved by the NADC.
  • Import of video files to each section header.
  • Will accept any video input including WiFi drain camera streams (via RTSP).
  • Impress your customers with a great CCTV report.
  • Lifelong support and updates provided with each valid license.
